  • NXS Fuel Cell 4 Gal seamless polyethylene cell inside
    20 gauge steel red powder coated can. Includes fuel cell,
    steel can, with tip-over valve vent, and 4" diameter
    screw on cap. -8 AN inlet and outlets vent. A D-ring cap is available
    and listed below. Pickup hose routed to right rear corner.
    Cell measures 13 x 11.25 x 9 tall.
    Kit form comes as shown with mounting frames and bolts.
    Will require 2 fittings -8AN to 3/8" barbed 90 degree part
    number NF108.
    ITEM#...NJ4FCKITF...$615

    Same above fuel cell kit with 1/4 turn cap.
    ITEM#..NJ4FC14CKIT...$525



    Fuel Cell with screw in cap.
    ITEM# NJ4FCSC..$480



    Fuel cell with 1/4 turn cap.
    Has inlet, outlet and vent installed.
    ITEM# NJ4FC14C...$390


    Fuel cell frame bolts (4 required).
    ITEM# NJ4FCFBOLT..$10 EA.


    Fuel cell frame bottom (requires welding) ITEM# NJ4FCFBOT..$60


    Fuel cell frame top
    ITEM# NJ4FCFTOP..$65


    Quarter turn cap to fit above fuel cells.
    Nice quality cap.
    ITEM# NXSAFQC...$55


    Fuel cell screw-on cap.
    ITEM# NXSAFCC..$102


    Tip over vent
    ITEM# NXSJFCROV...$29

    -8an bulkhead fitting
    with nut and washer.
    ITEM# NF8B...$12

    -8an tp 3/8 90 degree fitting
    ITEM# NF108...$14.75


    Aeromotive E85 fuel filter.
    10 micron has Micro-glass reuseable filter. Requires 2 fittings (NF113) listed below.
    ITEM# NAFS50..$205
    ITEM# NF113...$17


    Aeromotive E85 fuel filter.
    10 micron has Micro-glass reuseable filter. Includes AN6 male inlet and outlets.
    ITEM# NAFS45..$206


    NXS Fuel cell flange kit. Newly redesigned. This 2 piece flange kit once installed will stay mounted to any fuel cell, and allow for future changing of stock GSXR fuel pump without removing these flanges. Fuel pump becomes a simple bolt on installation. Comes complete as shown. ITEM# NFCFK...$90


    GSXR Aluminum Fuel Pump Install Ring. For use when installing a stock GSXR fuel pump into a plastic fuel cell. Has Oring groove on inside and outside of 5 screw holes. Requires 2 O-rings listed below.
    ITEM# NAGTF2..$40


    Fuel Pump ring screws (five with washers).
    ITEM# NXSFPSS...$3


    Fuel Pump stock oem used. Good used pumps checked.
    ITEM# NGSXRFP..$175


    Large outside O-ring for use with above NXS aluminum fuel ring. Needed when installing into plastic fuel cell.
    ITEM# NXSFPOR...$6


    Fuel Pump O-ring. STOCK size for use with NXS fuel cell. OR inside O-ring for use with above aluminum fuel ring.
    ITEM# NXSFPIR..$6


    Fuel cell roll over valve. Comes complete.
    ITEM# NXSJFCROV...$29


    Walbro fuel injection fuel pump. Uses two 10mm x AN6 fittings to connect to AN6 fittings. Other pumps require welding fittings. Fittings listed below and pump mount bracket if needed.
    ITEM# NXSWFP...$120

    Fuel Pump fittings for Walbro pump above. Two required.
    ITEM# NXSFBF2...$11.50ea

    Aluminum Walbro fuel pump mounting bracket Mounts to frame and is pinch clamp style bracket that holds pump in place.
    NXSWFPM...$35

    Aeromotive brand Fuel pump regulator.... Excellent for use with external fuel pumps. Up to 70# pressure.
    ITEM# NXSAFPR...$169

    Fragola brand
    AN6 to Male 3/8 Oring NPT. Use with Aeromotive regulator for connecting fuel line.
    Item# NF100 An6-3/8"......$8.75


    Fuel Pump F.I. hard plastic Nylon hose. Made for F.I. ..(10 ft of 5/16" Nylon F.I. hose).
    ITEM# NXSNFPH.....$30


    Fuel Pump hose 3/8" or AN6 push on hose).
    ITEM# N6HOSE...$4.15/ft


    In tank submersible -6AN hose. E-85 approved.
    ITEM# NSUB6.....$18/FT.

    TWO Fuel Pump quick connect fittings.
    ITEM# NXSQCF2..$15


    Quick release to AN6 fitting.
    This quick connect fitting fit GSXR and ZX10 fuel rails and GSXR fuel pump with opposite end to AN6 for fast disconnect that is reusable.
    ITEM# NXRQC..$17


    Fuel Line compression fitting AN6 to fuel line tube.
    ITEM# NXSFLCP.....$15


    Inline fuel guage fitting.
    AN6 male to AN6 male with 1/8" NPT female port.
    ITEM# NF001...$10


    AN6 to AN6 Female fitting.
    ITEM# NF106....$9

    Fragola AN6 90 degree bulkhead fitting.
    ITEM# NFB306..$6.75


    Fragola AN6 bulkhead nut ITEM# NFB306N...$1.75

    QRP brand liquid filled fuel pressure guage. Guage is needed when use of external pump and regulator is used.
    ITEM# NXSQFPG...$25

    E-85 approved heavy duty -6AN fuel line hose
    ITEM# NXRP6..$7/Ft


    E-85 approved heavy duty -6AN hose clamp.
    ITEM# NXRP6-C..$2

    Aeromotive brand liquid filled fuel pressure guage. Guage is needed when use of external pump and regulator is used.
    ITEM# NXSAFPG...$47


    Russel brand inline fuel filter. Has AN6 fittings on each end comes with 40 Micron reusable filter.
    ITEM# NXSRFF...$30


    Fragols brand fuel shut off valve. An6 outlet
    ITEM# NFFS06....$48.50

    GSXR 1000, 750, 600 Throttle Bodies (all years, all CCs).. price depends on year and model size... Prices start at.
    ITEM# NXSTB........$150

    Rubber velocity stacks all years. Price depends on year & size. Set of 4 start at
    ITEM# NXSVSR....$40

    GSXR 1000, 750, 600 Airbox clamp sets. (all years & all CCs)....
    2 clamps without sleeve
    ITEM# NXSABC....$20
    2 clamps with sleeve
    ITEM# NXSABC2...$31.
